2024 FORD Mustang Warning Lights and Indicators User Guide
This guide will explain the 2024 Ford Mustang warning lights and indicators. This tutorial will teach you your vehicle’s important signals for optimal functioning, from engine warnings to safety alerts.
2024 Ford Mustang Specs, Price, Features, Mileage (Brochure)
Video: 2024 FORD Mustang Cluster Warning Lights
Instrument Cluster
INSTRUMENT CLUSTER OVERVIEW
- A Gear indicator.
- B Outside air temperature.
- C Information on demand area.
- D Compass.
- E Speedometer.
- F Fuel gauge.
- G Distance to empty.
- H Odometer.
- I Drive mode indicator.
J Transmission position indicator. - K Tachometer.
- L Engine coolant temperature.
TACHOMETER
Indicates the engine speed.
SPEEDOMETER
Indicates the vehicle speed.
Secondary Speedometer
You can select a secondary speedometer that displays other measurement units.
Note: When only the primary speedometer is shown, the units are the same as the trip distance units selected. See Changing the Measurement Unit .
FUEL GAUGE
WHAT IS THE FUEL GAUGE
Indicates approximately how much fuel is in the fuel tank.
FUEL GAUGE LIMITATIONS
The fuel gauge may not provide an accurate reading when your vehicle is on an incline.
LOCATING THE FUEL FILLER DOOR
The arrow adjacent to the fuel pump symbol indicates on which side of your vehicle the fuel filler door is located.
WHAT IS THE LOW FUEL REMINDER
A low fuel level reminder displays and sounds when the distance to empty reaches 50 mi (80 km), 25 mi (40 km), 10 mi (20 km) and 0 mi (0 km).
Note: The low fuel reminder can appear at different fuel gauge positions depending on fuel economy conditions. This variation is normal.
WHAT IS DISTANCE TO EMPTY
Indicates the approximate distance your vehicle can travel on the fuel remaining in the tank. Changes in driving pattern can cause the value to not only decrease but also increase or stay constant for periods of time.
ENGINE COOLANT TEMPERATURE GAUGE
Indicates the engine coolant temperature.
WHAT ARE THE INSTRUMENT CLUSTER WARNING LAMPS
Warning lamps alert you to a vehicle condition that could become serious. Some lamps illuminate when you start your vehicle to make sure they work. If any lamps remain on after starting your vehicle, refer to the respective system warning lamp for further information.
INSTRUMENT CLUSTER WARNING LAMPS
Anti-Lock Brake System
If it illuminates when you are driving, this indicate malfunction. Your vehicle continues to have normal braking without the anti-lock brake system function. Have your vehicle checked as soon as possible. See
Anti-Lock Braking System
Battery
It illuminates when you switch the ignition on. If it illuminates when the engine is running, this indicates your vehicle requires service. Have your vehicle checked as soon as possible.
Brake System
Illuminates when you apply the parking brake and the ignition is
on. If it illuminates when your vehicle is moving, make sure the parking brake is released. If the parking brake is released, this indicates low brake fluid level or the brake
system requires service. Have your vehicle checked as soon as possible.
Note: Indicators may vary depending on region.
Door Ajar
It illuminates when you switch the ignition on and remains on if any door is open.
Electric Parking Brake
It illuminates or flashes when the electric parking brake requires service.
Note: Indicators may vary depending on region.
Driver Alert
Illuminates when you switch the
driver alert off.
Engine Coolant Temperature
If it illuminates, safely stop your vehicle and switch the vehicle off.
Fasten Seatbelt
It illuminates and a tone sounds until you fasten the seatbelts.
Front Airbag
See Airbags
Frost Warning Lamp
WARNING: Even if the temperature rises to above 39°F (4°C) there is no guarantee that the road is free of hazards caused by inclement weather.
It illuminates when the outside air temperature is 39°F (4°C) or below.
Hood Ajar
Illuminates when the ignition is on and you do not have the hood completely closed.
Low Beam Malfunction
Illuminates when there is a malfunction with the low beam headlamp bulb.
Low Fuel Level
It illuminates when the fuel level
is low.
Low Tire Pressure
It illuminates when your tire pressure is low. If illuminated, check your tire pressure as soon as possible. If it begins to flash at anytime, have the system checked as soon as possible.
Low Washer Fluid Level
It illuminates when the washer fluid is low.
Malfunction Indicator Lamp
Illuminates when the ignition is on and the engine is off, this is normal. If it illuminates when the engine is on this indicates the emission control system requires service. If it flashes, have your vehicle checked immediately.
See Starting and Stopping the Engine
Warning Lamps
It illuminates when the engine oil pressure is low.
Powertrain Malfunction
Illuminates when the powertrain or four-wheel drive require service. Have the system checked as soon as possible.
Trunk Ajar
Illuminates when the ignition is on and you do not have the trunk completely closed.
WHAT ARE THE INSTRUMENT CLUSTER INDICATORS
Indicators notify you of various features that are active on your vehicle.
INSTRUMENT CLUSTER INDICATORS
Adaptive Cruise Control
See Adaptive Cruise Control
Automatic High Beam
See Automatic High Beam Control
Auto Hold
Auto Hold Active
See Auto Hold
Auto Hold Unavailable
See Auto Hold
Auto-Start-Stop
See Auto-Start-Stop
Blind Spot Monitor
See Blind Spot Information System
Cruise Control
See Cruise Control
Drift Brake
Illuminates when you switch the drift brake on.
Front Fog Lamp
High Beam
See Using the High Beam Headlamps
Hill Start Assist
Illuminates when the system is not available.
Lamps On
See Exterior Lighting Control
Lane CenteringSee Lane Centering
Lane Keeping System
See Lane Keeping System
Launch Control
Launch Control Ready
See Track Apps
Launch Control Active
See Track Apps
Launch Control Not Ready
See Track Apps
Launch Control Ready With Traction Control Off
See Track Apps.
Launch Control Active With Traction Control Off
See Track Apps
Launch Control Not Ready With
Traction Control Off
See Track Apps
Over Speed Warning
It illuminates if the vehicle speed exceeds the over speed threshold.
Over speed thresholds vary depending on region.
Reverse Brake Assist
Stability Control and Traction Control
See Stability Control
See Traction Control
Shift Indicator
Illuminates to inform you that shifting to a higher gear as indicated may give better fuel economy and lower CO2 emissions. It does not illuminate during periods of high acceleration, braking or when you press the clutch pedal.
Turn Signal Lamps
See Using the Turn Signal Lamps
FAQs
Usually, the information is shown on the analog gauges or digital screen in front of the drive.
Yes, a lot of contemporary instrument clusters let you adjust the information that is shown using settings or controls that are located on the dashboard or steering wheel.
You can cycle through the various screens or menus by using the buttons or controls on the dashboard or steering wheel.
In most cases, settings permit alterations to contrast, color schemes, and brightness.
An automated or manual night mode is available on a lot of contemporary instrument clusters to change the brightness for improved visibility.
Yes, it frequently shows warnings for important problems like low tire pressure, low fuel, and maintenance reminders.
For detailed instructions, consult the owner’s manual as techniques may differ, but usually, there’s a setting in the cluster’s settings menu.
Certain models come with connectivity options to sync with smartphones for features like navigation or hands-free calling.
To understand the meaning of the symbol, consult the owner’s manual. If required, get in touch with a mechanic right away to resolve the problem.
Yes, authorized service centers may offer updates to add features or enhance performance.
Minor problems can usually be fixed by restarting the car or by following the owner’s manual’s reset procedure.
The cluster is factory calibrated, so calibration is usually not necessary, but if there are accuracy problems, a professional may need to make adjustments.
Use the controls, which are typically found on the steering wheel, to navigate through the menu options.
Yes, there may be options in the settings menu to enable or disable particular alerts according to individual preferences.
