2026 Audi Q7 Fuses and Fuse Box User Guide
This blog will help you understand the 2026 Audi Q7 fuses and fuse box, ensuring that all electrical components work properly. It covers fuse location, significance, and replacement procedures. Understand how to maintain fuses to keep your Q7’s safety and performance systems working properly.
Fuses and Bulbs
Fuses
Replacing Fuses
Driver’s side cockpit (left-hand drive/right-hand drive vehicle
cover C, the left side of the luggage compartment cover D
Fuses are installed in various locations in your vehicle. The following information only lists fuses that you can change yourself. To have other fuses changed, contact an authorized Audi dealer authorized Audi Service Facility. The following table does not list fuse locations that are not used. A fuse that has blown will have metal strips that
have burned through. The fuses are located in the footwell under the footrest (left-hand drive vehicle) or behind the cover (right-hand drive vehicle)). Additional fuses are located on the front side of the cockpit (driver’s side) and under the left cover in the luggage compartment.
- Switch the ignition and all electrical equipment off.
- Check the table that follows to see which fuse belongs to the affected equipment.
- Remove the screwdriver from the vehicle tool kit.
- Remove the appropriate cover.
- Remove the colored plastic bracket from the fuse panel, if present.
- Remove the clamps from the fuse panel cover in the footwells 1 or 2.
- Remove the fuse using the clip.
- Replace the blown fuse only with a fuse that has the same amp rating.
- Reinstaltlhe plastic bracket, if present.
- Install the cover.
Fuse color identification
| Colour | Rating in amperes |
| black | 1 |
| grey | 2 |
| purple | 3 |
| pink | 4 |
| light brown | 5 |
| brown | 7.5 |
| red (narrow) | 10 |
| light blue | 15 |
| yellow | 20 |
| white or transparent | 25 |
| light green | 30 |
| blue-green | 35 |
| orange | 40 |
| red (wide) | 50 |
Warning
Do not repair fuses and never replace a blown fuse with one that has a higher amp rating.
This can cause damage to the electrical system and increase the risk of fire.
Note
If a new fuse burns out again shortly after you have installed it, have the electrical system checked as soon as possible by an authorized ant pump, fuel pressure regulator Audi dealer or authorized Audi Service Facility.
Tips
Some of the equipment listed in the following tables applies only to certain model versions or certain optional equipment.
Fuse in footwell
| Fuse carrier 1 (brown) | |
| No. | Electrical equipment |
| 1 | Catalytic converter heater, camshaft ad- juster |
| 2 | Air mass meter, Lambda probes |
| 3 | Engine heating, injectors, exhaust flaps |
| 4 | Heating water pump, exhaust flaps, NOx sensor, particulate sensor, biodiesel sensor |
| 5 | Brake light sensor |
| 6 | Engine valves |
| 7 | Lambda probes, air mass meter |
| 8 | High-pressure pump, engine mountings |
| 9 | Engine components, engine relays |
| 10 | Oil pressure sensor, oil temperature sensor |
| 11 | 48 V coolant pump, 48 V starter alterna- tor, 12 V starter alternator |
| 12 | Engine valves |
| 13 | Engine cooling |
| 14 | Drive system control unit |
| 15 | Oxygen sensors |
| 16 | Fuel pump |
| Fuse carrier 2 (red) | |
| No. | Electrical equipment |
| 1 | Ignition coils |
| 4 | Electric compressor |
| 5 | Engine mountings |
| 6 | Windscreen washer system control unit |
| 7 | Dash panel |
| 8 | Air conditioner blowers |
| 9 | Control unit for driver assist systems |
| 10 | Emergency call and communication con- trol unit |
| 11 | Power unit start, clutch for electric drive system |
| 12 | Right headlight |
| Fuse carrier 3 (black) | |
| No. | Electrical equipment |
| 1 | Seat heating (front) |
| 2 | Wipers |
| 3 | Headlight electronics (left) |
| 4 | Panoramic glass roof |
| 5 | Door control unit, front left |
| 6 | Sockets |
| 7 | Door control unit, rear right |
| 8 | Left headlight |
| 9 | Headlight electronics (right) |
| 10 | Control unit for windscreen/headlight washer system |
| 11 | Door control unit, rear left |
| 12 | Auxiliary heating, exterior sound generator |
| Fuse carrier 4 (brown) | |
| No. | Electrical equipment |
|
1 |
Seat ventilation, seat electronics, interior mirror, A/C control console (rear), diagnos- tic connection |
| 2 | Control unit for vehicle electrical system, diagnostic interface |
| 3 | Engine sound control unit |
| 4 | Gear oil cooling valve |
| 5 | Power unit start, electric drive system |
| 8 | Night vision assist, active roll stabilisation |
| Fuse carrier 4 (brown) | |
| 9 | Adaptive cruise assist |
| 10 | External sound generator |
| 11 | Intersection assist, driver assist systems |
| 12 | Right headlight |
| 13 | Left headlight |
| 15 | USB connection |
| Fuse carrier 5 (red) | |
| No. | Electrical equipment |
| 1 | Anti-theft alarm system |
| 2 | Drive system control unit |
| 3 | Seat electronics (front), lumbar support |
| 4 | Selector lever for automatic gearbox |
| 5 | Horn |
| 6 | Parking brake |
| 7 | Diagnostic interface |
| 8 | Roof electronics control unit |
| 9 | Electronic toll collection system (ETC) |
| 10 | Airbag control unit |
| 11 | Electronic stabilisation control (ESC), anti- lock brake system (ABS) |
| 12 | Diagnostic connection, light sensor/rain sensor |
| 13 | Air conditioner |
| 14 | Door control unit, front right |
| 15 | Air conditioner compressor |
| 16 | Brake system pressure accumulator |
Fuses – dash panel
| Fuse carrier 1 (black) | |
| No. | Electrical equipment |
| 2 | Audi phone box, external aerial |
| 3 | Air conditioner, perfume function |
| 4 | Head-up display |
| 5 | USB ports with charging function |
| 7 | Steering column lock |
| 8 | Upper/lower display |
| 9 | Instrument cluster |
| 10 | DVD drive |
| 11 | Light switches, switch panels |
| 12 | Steering column electronics |
| 13 | MMI control dial |
| 14 | MMI infotainment control unit |
| 15 | Steering column adjustment |
| 16 | Heating for steering wheel |
Fuses in luggage compartment
| Fuse carrier 1 (black) | |
| No. | Electrical equipment |
| 1 | High-voltage heater, thermal manage- ment |
| 5 | Air suspension/suspension control |
| 6 | Automatic gearbox control unit |
| 7 | Seat heating (rear), A/C control console (rear) |
| 8 | Seat adjustment, third row of seats |
| 9 | Convenience system control unit, rear light (left-side) |
| 10 | Front belt tensioner (driver’s side) |
| 11 | Central locking for boot lid, fuel tank flap, luggage compartment cover |
| 12 | Boot lid control unit |
| Fuse carrier 2 (red) | |
| No. | Electrical equipment |
| 1 | Air conditioner blowers (rear) |
| 2 | Sound system |
| 3 | Emission control, engine sound control unit |
| 4 | A/C control console (rear) |
| 5 | Towing bracket (right lights) |
| Fuse carrier 2 (red) | |
| 6 | Towing bracket swivel motor |
| 7 | Towing bracket release |
| 8 | Towing bracket (left lights) |
| 9 | Electrical socket for towing bracket |
| 10 | Four-wheel sport differential |
| 11 | Emission control |
| 12 | Rear belt tensioner (driver’s side) |
| Fuse carrier 3 (brown) | |
| No. | Electrical equipment |
| 1 | Control unit for driver assist systems |
| 2 | Audi phone box |
| 3 | Lumbar support (right-side) |
| 4 | Side assist |
| 6 | Tyre pressure loss indicator |
| 7 | External aerial |
| 8 | Remote control receiver (auxiliary heater), fuel tank module |
| 10 | TV tuner, control unit for data exchange and telematics |
| 11 | Control unit for convenience access and start authorisation |
| 12 | Garage door opener |
| 13 | Reversing camera, surround view cameras |
| 14 | Convenience system control unit, rear light (right-side) |
| 15 | Rear belt tensioner (passenger’s side) |
| 16 | Front belt tensioner (passenger’s side) |
| Fuse carrier 4 (red) | |
| No. | Electrical equipment |
| 1 | Active roll stabilisation |
| 2 | Emergency cut-out connection for high- voltage battery |
| 3 | Coolant pump for high-voltage battery |
| 4 | Power electronics control unit |
| 5 | Brake servo |
| 6 | Voltage converter |
| 8 | Air conditioner compressor |
| 9 | Control unit for additional battery |
| 10 | High-voltage battery |
| Fuse carrier 4 (red) | |
| 11 | Charging system |
| 12 | Remote control receiver for auxiliary heat- er/air conditioning |
| 14 | Thermal management, coolant pumps |
| 15 | Thermal management control unit |
| Fuse carrier 5 (brown) | |
| No. | Electrical equipment |
| 7 | Seat heating (front) |
| 9 | Emission control |
| 10 | Seat heating (rear), A/C control console (rear) |
| 12 | Emission control |
Bulbs
Replacing bulbs
LED lights are maintenance-free and cannot be changed. For repairs, please contact a qualified workshop.
You should only change bulbs yourself if you have the skills required.
If you decide to change bulbs in the engine com-partment yourself, be aware of the safety risks involved.
