Mercedes (CL & S-Class) 2006 – 2014 Fuse Box Location and Diagrams Guide
This Guide covers Mercedes CL and S-Class fuse box locations and diagrams from 2006 to 2014, enabling you rapidly find and access fuses for maintenance, troubleshooting, and electrical system understanding.
Fuses
The electrical fuses in your vehicle serve to switch off malfunctioning power circuits.
If a fuse is blown, the component(s) and systems secured by that fuse will stop op-erating.
The following aids are available to help you replace fuses.
- Fuse chart
- Spare fuses
- Special fuse extractor
Blown fuses must be replaced by like fuses (recognizable by the color and amperage) with the amperage recommended in the fuse alloca-tion chart. A Mercedes-Benz Center will be hap-py to advise you.
Only change fuses while the vehicle is parked. First switch off all electrical consumers and turn off the ignition.
Warning
Only use fuses approved by Mercedes-Benz with the specified amperage for the system in question. Using other fuses may cause an overload leading to a fire, and/or cause damage to electrical components and/or systems.
Keep the fuse boxes free by contamination and wetness. Otherwise, electrical parts or sys-tems could be damaged.
Never attempt to repair or bridge a blown fuse. Have the cause determined and remedied by an authorized Mercedes-Benz Center.
Switch off the vehicle’s internal electrical functions.
when you are working on the fuses.
The electrical fuses are located in different fuse boxes:
- In the dashboard on the passenger side
- In the dashboard on the driver’s side
- Behind the rear center armrest
- In the engine compartment on the driv-er’s side
- In the engine compartment on the pas- senger side
Aids for replacing fuses
- Fuse chart
The fuse chart is located in the fuse box in the vehicle tool kit in the trunk page 611). The amperages of the fuses are also given there. - Spare fuses
The spare fuses are located in the vehicle tool kit in the trunk - Fuse extractor
The fuse extractor is located in the vehicle tool kit in the trunk
Instrument Panel Fuse Box No-1 (left)
Mercedes CL & S-Class 2006 – 2014
Fuse box location
Fuse box dashboard on the driver’s side
Fuse box diagram
| No | Fused function | Amp |
|---|---|---|
| 92 | Left front seat control unit | 40 |
| 93 | Restraint systems control unit USA version: Weight Sensing System (WSS) control unit |
7.5 |
| 94 | from 2009: Multifunction camera | 5 |
| 95 | – | – |
| 96 | Tire pressure monitor [RDK] control unit | 5 |
| 97 | W221: Audio/video controller control unit (rear entertainment system) | 7.5 |
| 98 | Rear entertainment system: DVD player (from 2009) | 7.5 |
| 99 | from 2009: COMAND display, SPLITVIEW display | 7.5 |
| 100 | from 2009: Media interface control unit | 5 |
| 101 | Rear entertainment system: Left rear display, Right rear display | 10 |
| 102 | Right front seat control unit | 40 |
| 103 | ESP control unit | 7.5 |
| 104 | Audio tuner control unit | 40 |
| 105 | – | – |
| 106 | Japanese version: Electronic toll collection (ETC) control unit Valid for South Korea as of 1.9.10: TV/tuner connector Valid for navigation; from 2009: Navigation processor |
1 |
| 107 | SDAR control unit (SIRIUS satellite radio) (W221 from 2009) Digital radio: Digital Audio Broadcasting control unit HD radio: High definition tuner control unit |
5 |
| 108 | W221: Rear air conditioning control unit | 5 |
| 109 | W221: Rear blower intermediate connector | 15 |
| 110 | W221: Left rear multicontour backrest control unit, Right rear multicontour backrest control unit | 7.5 |
| 111 | Rear multicontour seat or rear entertainment system (model 221): RCP [HBF] control unit | 5 |
| 112 | W221; up to 2008: Left front door control unit, Right front door control unit S 400 Hybrid: Front SAM control unit with fuse and relay module |
5 |
| 113 | S 400 Hybrid: DC/DC converter control unit | 5 |
Instrument Panel Fuse Box No-2 (Right)
Mercedes CL & S-Class 2006 – 2014
Fuse box location
Fuse box dashboard on the passenger side
- Opening
Open the respective door.
Using your hands, pull cover 1 in the direction of the arrow and remove. - Closing
Hook cover 1 into the opening at the front.
Press cover 1 back on until it engages.
Fuse box diagram
| No | Fused function | Amp |
|---|---|---|
| 70 | C216: Right door control unit W221: Right front door control unit |
40 |
| 71 | Keyless Go control unit | 15 |
| 72 | S 400 Hybrid: Pyrotechnical separator | 7.5 |
| 73 | Japanese version: COMAND controller unit TELE AID emergency call system (from 2009): Emergency call system control unit |
5 |
| 74 | TLC [HDS] control unit (Remote trunk closing) | 30 |
| 75 | S 400 Hybrid: Battery management system control unit, Power electronics control unit | 10 |
| 76 | S 400 Hybrid: Vacuum pump relay (+) | 15 |
| 76 | Valid for model 221 with engine 642.8: AdBlue® relay supply | – |
| 77 | Advanced sound system: Sound amplifier (from 2009) | 50 |
| 78 | S 65 AMG with engine 275: Additional fan relay (from 2009) Valid for model 221 with engine 642.8: AdBlue® relay supply (from 2009) |
25 |
| 78 | S 400 Hybrid, CL 63 AMG with engine 157, 278: Charge air cooler circulation pump (from 2009) | 15 |
| 79 | Alarm signal horn with additional battery | 7.5 |
| 80 | C216: Left door control unit W221: Left front door control unit |
40 |
| 81 | C216: Rear control unit | 30 |
| 81 | W221: Left rear door control unit | 40 |
| 82 | C216: Rear control unit | 30 |
| 82 | W221: Left rear door control unit | 40 |
| 83 | Intelligent servo module for DIRECT SELECT | 30 |
| 84 | Advanced sound system: Digital sound processor (from 2009) | 20 |
| 85 | Valid for AMG: Illuminated door sill moldings (from 2009) | 10 |
| 86 | – | – |
| 87 | – | – |
| 88 | – | – |
| 89 | – | – |
| 90 | Stationary heater: STH heater unit (C216), STH or HB heater unit (W221) | 20 |
| 91 | Stationary heater: STH radio remote control receiver S 400 Hybrid: Front SAM control unit with fuse and relay module |
5 |
Rear Fuse Box
Mercedes CL & S-Class 2006 – 2014
Fuse box location
- Cover
- Opening
Swing down center armrest.
Open cover behind center armrest.
Pull cover1 forward in direction of arrow. - Closing
Press cover1 backward and engage.
- Opening
Fuse box diagram
| № | Fused function | Amp |
|---|---|---|
| 115 | Heated rear window | 50 |
| 116 | Valid for engine 157, 275, 278: Charge air cooler circulation pump Valid for engine 156: Engine coolant circulation pump S 400 Hybrid: Power electronics circulation pump 2 |
10 |
| 117 | Rear cigar lighter | 15 |
| 118 | Valid for engine 272, 273, 642: Fuel pump (up to 2008) Valid for model 221 with engine 629, 642: Fuel pump (from 2009) |
30 |
| 118 | S 400 Hybrid: Power electronics circulation pump 1 Valid for model 642.8 and engine 651 as of 1.6.11: Refrigerant compressor with magnetic |
15 |
| 119 | Front central operating unit | 7.5 |
| 120 | – | – |
| 121 | Audio tuner control unit | 10 |
| 122 | COMAND controller unit | 7.5 |
| 123 | W221: Right front reversible emergency tensioning retractor | 40 |
| 124 | W221: Left front reversible emergency tensioning retractor | 40 |
| 125 | up 31.5.09: Voice control system (VCS) control unit | 5 |
| 126 | Overhead control panel control unit | 25 |
| 127 | Lumbar pump (from 2009) Multicontour seat pneumatic pump (Left/right front multicontour seats) Pneumatic pump for dynamic seat control (Left and right dynamic multicontour seat) |
30 |
| 128 | Valid for engine 275 (up to 2008): Fuel pump control unit Valid for engine 156, 157, 272, 273, 275, 276, 278, 642 (from 2009): Fuel pump control unit |
25 |
| 129 | up to 2008: Overhead control panel control unit (Power glass tilting/sliding roof) from 2009: UPCI (Universal Portable Cell Phone Interface) control unit |
25 |
| 130 | Electric parking brake controller unit | 30 |
| 131 | Rear window antenna amplifier module | 7.5 |
| 133 | Trailer recognition control unit Reversing camera (as of 1.9.10) |
15 |
| 134 | Luggage compartment socket | 15 |
| 135 | Park Assist; up 2008: Radar sensors control unit (SGR) Front short range radar sensor unit Rear short range radar sensor unit DISTRONIC PLUS up to 31.8.10 or Blind Spot Assist or Adaptive cruise control Plus Light: Radar sensors control unit (SGR) (from 2009) PARKTRONIC or Exclusive parking assist: PTS control unit |
7.5 |
| 136 | Valid for model 221 with engine 642.8: AdBlue® control unit | 7.5 |
| 137 | Reversing camera (as of 1.9.10) | 7.5 |
| 138 | Navigation processor (from 2009) (up to 31.8.10) Emergency call system control unit (from 2009) Japanese version: TV/tuner connector (from 2009) |
5 |
| 139 | Rear backrest refrigerator box | 15 |
| 140 | Rear cigar lighter with ashtray illumination connector 115 V socket (from 2009) |
15 |
| 141 | Reversing camera control unit | 5 |
| 142 | Parktronic system (PTS) control unit Distronic Plus: Radar sensors control unit (SGR) Valid as of 1.9.10 for DISTRONIC PLUS and Active Blind Spot Assist or Active Lane Keeping Assist: Video and radar sensor system control unit |
7.5 |
| 143 | Rear seats control unit | 25 |
| 144 | Rear seats control unit | 25 |
| 145 | Trailer recognition control unit (up to 2008) Trailer hitch socket (13-pin) (from 2009) |
20 |
| 146 | Trailer recognition control unit | 25 |
| 147 | up to 2008: TLC [HDS] control unit (Remote trunk closing) | 30 |
| 148 | up to 2008: Universal Portable CTEL Interface (UPCI [UHI]) control unit | 7.5 |
| 148 | from 2009: Panoramic sliding sunroof circuit 30 connector sleeve | 25 |
| 149 | up to 2008: Voice control system (VCS [SBS]) control unit | 5 |
| 149 | from 2009: Panoramic sliding sunroof control module | 25 |
| 150 | TV combination tuner (analog/digital) Japanese version: TV/tuner connector (from 2009) |
7.5 |
| 151 | W221; up to 2008: Electric parking brake controller unit | 25 |
| 151 | W221; from 2009: Trailer recognition control unit | 20 |
| 152 | W221: Rear window antenna amplifier module | 7.5 |
| 152 | 115 V socket: DC/AC converter control unit | 25 |
| Relay | ||
| M | Terminal 15 relay | |
| N | Terminal 15R relay | |
| O | Power outlet relay | |
| P | Heated rear window relay | |
| Q | Valid for engine 156, 157, 275, 278, 629: Circulation pump relay S 400 Hybrid: Valid for model 221.095/195: Power electronics circulation pump relay 2 |
|
| R | Cigar lighter relay | |
| S | Fuel pump relay Valid for engine 642.8 and engine 651 as of 1.6.11: Connected through the fuel pump: Refrigerant compressor magnetic clutch S 400 Hybrid: Power electronics circulation pump relay 1 |
Engine Compartment Fuse Box
Mercedes CL & S-Class 2006 – 2014
Fuse box location
Fuse box, driver’s side (example illustration from S 550)
- 4 screws
- Cover
- Jumper
- Opening
Take the crank from the Operator’s
Manual pouch.
Loosen screws1 with crank.
Remove jumper3.
Remove cover2. - Closing
Attach cover2.
Attach jumper3.
Tighten screws1 with crank.
- Opening
Fuse box diagram
| No | Fused function | Amp |
|---|---|---|
| 20 | Valid for engine 629, 642, 651: CDI control unit Valid for engines 156, 157, 272, 273, 275, 276, 278: ME-SFI [ME] control unit |
10 |
| 21 | Valid for engines 156, 157, 272, 273, 275, 276, 278: Terminal 87 Ml i connector sleeve Valid for model 221 with engine 629 and engine 642: CDI control unit Fuel pump relay Valid for model 221 with engine 651: Quantity control valve |
20 |
| 22 | Valid for engines 156, 157, 272, 273, 276, 278: Terminal 87 connector sleeve | 15 |
| 23 | up to 2008: Terminal 87 connector sleeve Valid for engine 275 (model 216): Terminal 87 M1 i connector sleeve Valid for engine 273 (model 216): Terminal 87 M2e connector sleeve Valid for engine 272, 273 (model 221): Terminal 87M2i connector sleeve Valid for engine 642: Terminal 87 connector sleevefrom 2009: Valid for engine 156, 157, 272, 273, 275, 276, 278: Terminal 87 connector sleeve Valid for model 221 with engine 629 and engine 642: Terminal 87 connector sleeve Valid for engine 156, 157, 272, 273, 276, 278: Terminal 87M2e connector sleeve Valid for engine 275: Terminal 87 M2i connector sleeve Valid for model 221 with engine 629 and engine 642: Terminal 87 connector sleeve Valid for model 221 with engine 651: Rear SAM control unit with fuse and relay module |
20 |
| 24 | Valid for engines 157, 272, 273, 276, 278: Terminal 87Mle connector sleeve Valid for engine 642: CDI control unit |
25 |
| 25 | Instrument cluster | 7.5 |
| 26 | Left front lamp unit | 10 |
| 27 | Right front lamp unit | 10 |
| 28 | Valid for engine 275: EGS control unit Valid without engine 275: Fully integrated transmission control (VGS) control unit |
7.5 |
| 29 | Rear SAM control unit with fuse and relay module | 5 |
| 30 | Valid for engine 629, 642, 651: CDI control unit Valid for engines 156, 157, 272, 273, 275, 276, 278: ME-SFI [ME] control unit Fuel pump control unit |
7.5 |
| 31 | S 400 Hybrid: Electric refrigerant compressor | 5 |
| 32 | Valid for model with ECO start/stop function: Transmission oil auxiliary pump control unit S 400 Hybrid: Transmission oil auxiliary pump control unit |
15 |
| 33 | Valid as of 1.9.10 without model S 400 Hybrid: ESP control unit S 400 Hybrid: Battery management system control unit DC/DC converter control unit Power electronics control unit |
5 |
| 34 | S 400 Hybrid: Regenerative braking system control unit | 5 |
| 35 | Electric parking brake controller unit | 5 |
| 36 | Data link connector (Pin 16) | 10 |
| 37 | For EIS control unit | 7.5 |
| 38 | Central gateway control unit | 7.5 |
| 39 | Instrument cluster | 7.5 |
| 40 | Upper control panel control unit | 7.5 |
| 41 | Slave wiper motor | 30 |
| 42 | Master wiper motor | 30 |
| 43 | Front cigar lighter with ashtray illumination | 15 |
| 44 | – | – |
| 45 | S 400 Hybrid: Power electronics circulation pump 1 | 5 |
| 46 | W221 with Active Body Control (ABC), model 216: ABC control unit W221 without Active Body Contro (ABC): AIRmatic with ADS control unit |
15 |
| 47 | Front SAM control unit with fuse and relay module Steering column up/down motor |
15 |
| 48 | up to 2008: Front SAM control unit with fuse and relay module
from 2009: Steering column in/out motor |
15 |
| 49 | Steering column module | 10 |
| 50 | AAC [KLA] control unit | 15 |
| 51 | up to 2008: COMAND display | 7.5 |
| 51 | from 2009: COMAND display SPLITVIEW display |
5 |
| 52A | W221: Left fanfare horn Right fanfare horn |
15 |
| 52B | W221, C216: Left fanfare horn Right fanfare horn |
15 |
| 53 | – | – |
| 54 | AC air recirculation unit | 40 |
| 55 | Valid for gasoline engine: Electric air pump | 60 |
| 56 | W221 without Active Body Contro (ABC): AIRmatic compressor unit | 40 |
| 57 | up 2008: Wiper park position heater | 40 |
| 57 | from 2009: Wiper park position heater | 30 |
| 60 | from 2009: Electrohydraulic power steering | 5 |
| 61 | C216; W221 – from 2009: Restraint systems control unit | 7.5 |
| 61 | W221; up to 2008: Restraint systems control unit | 10 |
| 62 | Night View Assist control unit | 5 |
| 63 | Valid for model 221 with engine 629 and engine 642 as of 1.9.08: Fuel filter condensation sensor with heating element | 15 |
| 64 | W221 as of 1.9.06: Driver NECK-PRO head restraint solenoid, Front passenger NECK-PRO head restraint solenoid | 7.5 |
| 64 | W221 as of ’09: Driver NECK-PRO head restraint solenoid, Front passenger NECK-PRO head restraint solenoid | 10 |
| 65 | Valid as of 1.6.09: 12 Volt connector in glove box | 15 |
| 66 | DTR controller unit (Distronic or Distronic Plus) | 7.5 |
| Relay | ||
| A | Air pump relay | |
| B | Air suspension compressor relay | |
| C | Terminal 87 relay, engine | |
| D | Terminal 15 relay | |
| E | Terminal 87 relay, chassis | |
| F | Fanfare horn relay | |
| G | Terminal 15R relay | |
| H | Circuit 50 relay, starter | |
| J | Circuit 15 relay, starter | |
| K | Wiper park heater relay |
Engine Pre-Fuse Box
Mercedes CL & S-Class Up to 2008 From 2009
| No | Fused function | Amp |
|---|---|---|
| 1 | Starter | 400 |
| 2 | Not valid for engine 642: Alternator Valid for engine 642: Alternator |
150/200 |
| 3 | – | 150 |
| 4 | AAC with integrated control additional fan motor | 150 |
| 5 | Valid for engine 642: PTC heater booster | 200 |
| 6 | Front SAM control unit with fuse and relay module | 200 |
| 7 | ESP control unit | 40 |
| 8 | ESP control unit | 25 |
| 9 | Front SAM control unit with fuse and relay module | 20 |
| 10 | Vehicle power supply control unit | 7.5 |
| No | Fused function | Amp |
|---|---|---|
| 3 | Rear SAM control unit with fuse and relay module | 150 |
| 4 | ECO start/stop function: ECO start/stop function relay S 400 Hybrid: DC/DC converter control unit Heated windshield: Heated windshield control unit |
150 |
| 5 | Valid for model 221 (Electrical preinstallation for rental vehicle): Special vehicle multifunction control unit (SVMCU [MSS]) | 125 |
| 5 | S 400 Hybrid: Vacuum pump | 40 |
| 6 | Right dashboard fuse box | 80 |
| 7 | Valid for model 221 with engine 629, 642, 651: PTC heater booster Valid for model 221 (Electrical preinstallation for rental vehicle): Special vehicle multifunction control unit (SVMCU [MSS]) |
150 |
| 8 | Front SAM control unit with fuse and relay module | 80 |
| 9 | Left dashboard fuse box | 80 |
| 10 | Rear SAM control unit with fuse and relay module | 150 |
Interior Pre-fuse Box
Mercedes CL & S-Class Up to 2008 from 2009
| No | Fused function | Amp |
|---|---|---|
| 1 | Front prefuse box (via on-board electrical network line pyrofuse) | |
| 2 | Heated windshield control unit | 125 |
| 3 | Right instrument panel fuse box | 80 |
| 4 | Rear SAM control unit with fuse and relay module | 200 |
| 5 | Special vehicle multifunction control unit (SVMCU [MSS]) | 100 |
| 6 | Rear SAM control unit with fuse and relay module | 150 |
| 7 | Front SAM control unit with fuse and relay module | 100 |
| 8 | Left instrument panel fuse box | 80 |
| 9 | Front SAM control unit with fuse and relay module | 5 |
| 10 | C216: Emergency call system control unit | 5 |
AdBlue Fuse Block
Mercedes CL & S-Class 2006 – 2014
| No | Fused function | Amp |
|---|---|---|
| A | AdBlue control unit | 7.5 |
| B | Heater circuit 1 | 20 |
| C | Heater circuit 2 | 20 |
| D | Spare | – |
